PlayStation S-Video Cable
-
PlayStation S-Video Cable
A generic S‑Video cable for PlayStation consoles (PS1, PS2, PS3) to televisions via the Multi AV port, providing improved video quality over composite by separating the brightness (luma) and colour (chroma) signals.
Description
This S-Video Cable provides improved image quality for a range of PlayStation consoles. The PlayStation family from the original PlayStation through to the initial PS3 models used the Multi AV port, a proprietary connector that allowed different types of analogue video cables to be attached. While the bundled cables were usually composite (yellow video + red/white audio), Sony also supported higher‑quality outputs such as S‑Video, RGB SCART (in PAL regions), and component.
A generic s‑video cable plugs into the Multi AV port on one end and provides an S‑Video connector plus stereo RCA audio on the other. The advantage of s‑video is that it separates the video signal into two channels: luma (brightness) and chroma (colour), which reduces colour bleeding and dot crawl compared to composite. The result is a noticeably sharper image, especially on CRT televisions or capture devices that accept s‑video.
These cables were widely available from third‑party manufacturers, inexpensive, usually bundled with both s‑video and composite connectors on the same lead, and compatible across multiple generations of PlayStation hardware. Build quality can vary, but functionally they all rely on the same pinout of the Multi AV port.
